ClairSaf-Speed
Solar-powered Radar Speed Sign
ClairSaf-Speed solar-powered radar speed sign is an eco-friendly traffic safety device designed to monitor and display vehicle speeds in real-time. Powered by solar energy, it operates efficiently without the need for external electricity, making it ideal for remote or off-grid locations. Equipped with radar technology, it accurately detects the speed of approaching vehicles and displays it on a highly visible LED screen. This encourages drivers to adhere to speed limits, enhancing road safety and reducing the risk of accidents. Its durable construction and low maintenance requirements make it a reliable solution for promoting safer driving habits in various settings.
Key Features
  • Speed Detection Range: 4-400KM/H
  • Distance Detection Range: Longitudinal coverage of up to 150 meters.
  • LED Display Brightness: Luminous intensity of 4,800-6,800 mcd for red and 8,500-10,500 mcd for green.
  • LED Viewing Angle: ≥30 degrees
  • LED Visible Distance: ≥300 meters
  • Solar Panel Power: 80W
  • Battery Capacity: 12V/65AH, lead-acid. The device can operate continuously for 120 hours in rainy or overcast conditions.
  • Operating Temperature: -30 to 70˚C
  • IP Rate: LED display IP54, Radar IP65
  • Radar Frequency: 24.15GHz
  • Dimension: Pole, 4500*110mm (to be provided by the customer). Speed display sign: 1300*650*90mm (ClairSaf-Speed-88), 1850*123*90mm (ClairSaf-Speed-188). Battery box: 500*353.2*277mm
Customizable Features
  • Display content/messages
  • Speed limit settings
  • Display colors
  • Language options
  • Size and design of the Display Sign
  • Display of plate number (local license plate number resources for training)
  • Vehicle classifications (with ClairWav camera integrated radar)
  • Lithium battery optional.

Contact us for your detailed customization requirements.

Technical Documents
ClairSaf-Speed Datasheet
PDF file, 3.2M
Download
