The Geomagnetic Vehicle Detection System utilizes wireless sensors to detect the presence and movement of vehicles. By capturing data on traffic flow, speed, average speed, occupancy time, vehicle length, queue length, and other parameters, it enables macroscopic monitoring of urban road conditions. This system provides rich and precise real-time detection data for traffic signal control, serves as the foundation for traffic flow data in traffic guidance systems, and offers essential design considerations for urban traffic organization optimization and infrastructure planning. ClairGeo MSeries supports X,Y,Z axis detection and directional wireless communication for higher anti-interference capabilities.
A Perfect Substitute of Inductive Loop Detectors
The loop outputs typically include TTL High-Level Effective, TTL Low-Level Effective, Normally Open Digital Output, and Normally Closed Digital Output.
For inductive loop detectors, the output modes usually consist of Pulse and Dry Contact.
AI & neural network video proceFor inductive loop detectors, the output modes usually consist of Pulse and Dry Contact.
Geomagnetic Detector is fully capable of emulating the output modes of inductive loop detectors, achieving two-state outputs for "vehicle present" and "no vehicle."
The occupancy time can be determined based on the length and width of the installed inductive loop. The output function can be customized according to specific needs.
Perfect Match with SCATS System
Location: Stop line online, 1-3 meters after the stop line
Configuration: Single lane configuration
Detection area: Detection area along the direction of travel, precise within 1.5-2 meters
Data: Time precision of 250ms, signal indicating the presence of a vehicle
Our double-layer sealing system, featuring a screw-less integration and ultrasonic welding, ensures impeccable waterproofing. Crafted from advanced materials, it offers reliable protection, simplified user experience, and robust durability, making it an ideal choice for applications requiring uncompromised waterproof assurance.
Robust Structural Design: Impact Resistance
The cylindrical bottom design of our product efficiently disperses pressure to the ground magnetic detector, while the top, with a reduced volume, minimizes stress area. The shell is reinforced internally and externally, ensuring effective force dissipation and robust support. Internally, it is equipped with a secure lock and shock-absorbing fixing device. Rigorous testing, including enduring 7 tons of compression and 450,000 impact tests, validates the product's durability and reliability under demanding conditions.
Expected 10-year Lifespan
18AH battery (theoretical calculation) operates for over 10 years.
Test environment:
7.8ms magnetic field sampling rate (ensuring accuracy for 120km/h speed testing as a basis)
Single sampling time of 50us (ensuring ultra-low power consumption)
